Astral Victoria Plus Silent Pool Pump

Product Name	Price	Delivery	Qty
Astral Victoria Plus Silent 0.50CV, 230V electric pump Cód.ASTR65557	€572.00 €430.00
Electric pump Astral Victoria Plus Silent 0.75CV, 230V Cód.ASTR65560	€644.52 €372.00
Electric pump Astral Victoria Plus Silent 1.00CV, 230V Cód.ASTR65562	€658.05 €380.00
Electric pump Astral Victoria Plus Silent 1.50CV, 230V Cód.ASTR65564	€793.35 €462.00
Electric pump Astral Victoria Plus Silent 2.00CV, 230V Cód.ASTR65566	€845.01 €493.00
Electric pump Astral Victoria Plus Silent 3.00CV, 230V Cód.ASTR65569	€886.83 €518.00
Electric pump Astral Victoria Plus Silent 1.00CV, 400V Cód.ASTR65563	€746.61 €433.00
Electric pump Astral Victoria Plus Silent 1.50CV, 400V Cód.ASTR65565	€814.26 €474.00
Electric pump Astral Victoria Plus Silent 2.00CV, 400V Cód.ASTR65567	€940.95 €581.00
Electric pump Astral Victoria Plus Silent 3.00CV, 400V Cód.ASTR65570	€980.31 €597.88

Product Description

AstralPool Victoria Plus SILENT

New generation of self-priming filtration pumps that replace Victoria Plus

It is a single-stage centrifugal pump with self-priming capacity with single-phase and three-phase motors ranging from 1/3 to 3 horsepower. The Victoria Plus generation of pool pumps provides a high-performance, top-quality pump.

The great advantage of this pool pump over the Astral Sena is that the Victoria Plus has a more robust motor that always works in good conditions with a voltage margin of +/- 10% in relation to the nominal voltage of the motor. In other words, it is a motor that is more robust to fluctuations in the mains power supply, therefore having a longer lifespan. It is also prepared for environments with high humidity and temperature.

Furthermore, all metal parts in contact with water are made of AISI 316 stainless steel, to ensure a long working life. Silicon carbide mechanical seal and bearings are designed to work at high temperatures and high levels of humidity. Furthermore, the IP-55 rating prevents solid and liquid particles from entering the motor.

We can say that the Victoria Plus pump meets all application needs in private pools and SPAs , in all types of environments and locations.

Specification

Model			THE			P1	P2	WHICH _NAME	H _NOM
230 V II 50Hz	230/400V 50Hz	HP	230V II	400V III	230V III	kW	kW	m ³ /h	m
65557	65558	½	2.6	1	1.8	0.6	0.45	11	8
65560	65561	¾	2.9	1.2	2.1	0.65	0.47	11	10
65562	65563	1	4.3	1.9	3.3	1	0.76	16	10
65564	65565	1½	5.8	2.3	4.1	1.35	1.04	22.5	10
65566	65567	2	7.3	3	5.2	1.65	1.32	226.5	10
65569	65570	3	10.3	4.3	7.3	2.35	1.89	34	10

VOLUME	CIRCULATION	FILTRATION	Ø FILTER	PUMP
30 m³	8 h	50 m³/h/m²	300 mm	0.33 HP
40-50 m³	8 h	50 m³/h/m²	400 mm	0.50 HP
70-80 m³	8 h	50 m³/h/m²	500 mm	0.50 HP
90-100 m³	8 h	50 m³/h/m²	600 mm	0.75 HP
100-140 m³	8 h	50 m³/h/m²	750 mm	1 HP
140-170 m³	8 h	50 m³/h/m²	800 mm	1.50 HP
170-200 m³	8 h	50 m³/h/m²	900 mm	2 HP
