Product Name	Price	Delivery	Qty
Electric pump Baico Etna2 300-4M, 0.75CV, 230V Cód.BAIETNA23004M	€234.15 €172.80
Electric pump Baico Etna2 350-4M, 1.00CV, 230V Cód.BAIETNA23504M	€248.78 €183.60
Electric pump Baico Etna2 420-4M, 1.50CV, 230V Cód.BAIETNA24204M	€281.30 €207.60
Electric pump Baico Etna2 350-4T, 1.00CV, 400V Cód.BAIETNA23504T	€269.92 €199.20
Electric pump Baico Etna2 420-4T, 1.50CV, 400V Cód.BAIETNA24204T	€295.93 €218.40

Product Description

Applications

Self-priming single-cell centrifugal pumps with pre-filter, designed for water recirculation in swimming pools. Incorporates a cap for completely emptying the water from the pump body in periods of low temperatures.

The Etna series centrifugal pool pumps meet all pumping requirements in medium and large pools, water games, wellness facilities and spas .

Operation

Fluid - Water;
Maximum liquid temperature - 30 ºC ;

Construction Features

Pump body - Polypropylene with 30% fiberglass;
Pump Base - Polypropylene;
Turbine - Noryl with 30% fiberglass;
Motor Shaft - Stainless Steel;
Seal - Ceramic-graphite mechanical seal;

Electric Motor

Submersible motors with IP55 protection rating and class F insulation.
Single-phase 230 V - 50 Hz with permanent capacitor or three-phase 400V - 50Hz .

Specification

Model	Impulse	Kg	Package Dimensions
ETNA 2 130-4M	2 ¼" x 2 ¼"	7	560x275x390mm
ETNA2 220-4M	2 ¼" x 2 ¼"	8	560x275x390mm
ETNA2 300-4M	2 ¼" x 2 ¼"	9	560x275x390mm
ETNA 2 350-4M	2 ¼" x 2 ¼"	11	560x275x390mm
ETNA2 350-4	2 ¼" x 2 ¼"	11	560x275x390mm
ETNA2 420-4M	2 ¼" x 2 ¼"	12	560x275x390mm
ETNA2 420-4	2 ¼" x 2 ¼"	12	560x275x390mm

Model	V	P1 [kW]	P2 [HP]	I [A]	μF	l/min	100	150	200	300	350	400
Model	V	P1 [kW]	P2 [HP]	I [A]	μF	m ³ /h	6	9	12	18	21	24
ETNA 2 130-4M	1-230	0.37	0.33	1.9	7	-	5	3.8	-	-	-	-
ETNA2 220-4M	1-230	0.55	0.5	2.7	10	-	8	7.2	5	-	-	-
ETNA2 300-4M	1-230	0.75	0.75	3.8	10	-	10.7	9.1	8	4	-	-
ETNA 2 350-4M	1-230	0.9	1	4.6	15	-	15.7	14.4	12.8	8.8	7	-
ETNA2 350-4	1-220/400	1.1	1	3.4/2	/	-	15.7	14.4	12.8	8.8	7	-
ETNA2 420-4M	1-230	1.5	1.5	7	30	-	17.6	16	15.5	11.7	8	5
ETNA2 420-4	1-220/400	1.5	1.5	4.3/2.5	/	-	17.6	16	15.5	11.7	8	5

VOLUME	CIRCULATION	FILTRATION	Ø FILTER	PUMP
30 m³	8 h	50 m³/h/m²	300 mm	0.33 HP
40-50 m³	8 h	50 m³/h/m²	400 mm	0.50 HP
70-80 m³	8 h	50 m³/h/m²	500 mm	0.50 HP
90-100 m³	8 h	50 m³/h/m²	600 mm	0.75 HP
100-140 m³	8 h	50 m³/h/m²	750 mm	1 HP
140-170 m³	8 h	50 m³/h/m²	800 mm	1.50 HP
170-200 m³	8 h	50 m³/h/m²	900 mm	2 HP
